◆ Processing materials: Virgin PP granules or add 5%_30% CaCO₃
◆ Main products: Jumbo bags
|
Model |
SJPL-Z140×33-1500×2 |
SJPL-Z150×33-2100×2 |
|
*Max. melting capacity |
750kg/h |
1000kg/h |
|
Main motor power |
250kw |
280kw |
|
Screw diameter |
Ф140mm |
Ф150mm |
|
Die lip length |
1500mm×2 |
2100mm×2 |
|
**Max. production speed |
360m/min |
460m/min |
|
Number of winde |
320spindles |
460spindles |
|
Overall dimensions （L×W×H)） |
55000×5000×3500mm |
68000×6000×3650mm |
*Related to the use of melt pump
**Related to the fineness of raw materials and products
Optional device
|
Multi-station weighing and mixing system High-precision gear pump system Automatically controlled flat die Film thickness measurement system Three-folding device |
Additional heat setting roller Chill roll system Chiller Cooling tower |
Specification and dimensions are subject to change without prior notice.
