◆ Processing Materials: Virgin PP/HDPE/LDPE granules, or add 10% - 30% CaCO₃
◆ Main products: Rice bags, Flour bags, Fertilizer bags, Cement bags, etc
◆ Production speeds of up to 500 m/min
◆ The production capacity can reach 1000 kg/h
◆ High-quality and low-weight flat yarm
◆ High-strength flat yarn
|
Model Mode |
SJPL-G120X33-1800 |
SJPL-G130X33-2100 |
SJPL-G140X33-2600 |
SJPL-G150X33-3000 |
|
*Max. melting capacity |
550kg/h |
650kg/h |
800kg/h |
1000kg/h |
|
Main motor power |
160kw |
200kw |
250kw |
280kw |
|
Screw diameter |
Ф120mm |
Ф130mm |
Ф140mm |
Ф150mm |
|
Die lip length |
1800mm |
2100mm |
2600mm |
3000mm |
|
**Max.production speed |
500m/min |
500m/min |
500m/min |
500m/min |
|
Number of winder |
260spindles |
380spindles |
480spindles |
580spindles |
|
Overall dimensions （L×W×H） |
41000×5000×3500mm |
52000×5500×3500mm |
57000×6000×3500mm |
63000×6500×3500mm |
*Related to the use of melt pump
**Related to the fineness of raw materials and products
Optional device
|
Multi-station weighing and mixing system High-precision gear pump system Automatically controlled flat die Film thickness measurement system Three-folding device |
Fibrillation Unit Additional heat setting roller Chill roll system Chiller Cooling tower |
Specification and dimensions are subject to change without prior notice.
