◆ Processing Materials：Virgin PP / HDPE / LDPE granules, 50% recycled material, or with 10% - 30%CaCO₃
◆ Main products: Jumbo bags
◆ Production speeds of up to 400 m/min
◆ The production capacity can reach 1000 kg/h
|
Model |
SJPL-Z110×33-1100/1500 |
SJPL-Z120×33-1300/1800 |
SJPL-Z130×33-1500/2100 |
SJPL-Z150×33-2100/3000 |
|
*Max. melting capacity |
400kg/h |
600kg/h |
750kg/h |
1100kg/h |
|
Main motor power |
110kw |
160kw |
200kw |
280kw |
|
Screw diameter |
Ф110mm |
Ф120mm |
Ф130mm |
Ф150mm |
|
Die lip length |
1100/1500mm |
1300/1800mm |
1500/2100mm |
2100/3000mm |
|
**Max. production speed |
400m/min |
400m/min |
400m/min |
400m/min |
|
Number of winder |
220spindles |
260spindles |
300spindles |
430spindles |
|
Overall dimensions（L×W×H） |
39500×3800×3500mm |
42000×5000×3500mm |
46000×5500×3500mm |
52000×6000×3500mm |
*Related to the use of melt pump
**Related to the fineness of raw materials and products
Optional device
|
Multi-station weighing and mixing system High-precision gear pump system Automatically controlled flat die Film thickness measurement system Three-folding device |
Fibrillation Unit Additional heat setting roller Chill roll system Chiller Cooling tower |
Specification and dimensions are subject to change without prior notice.
