◆ Processing materials: Virgin HDPE granules, or with 5%-30% CaCO₃
◆ Main products: Waterproof tarpaulin, Shade net , Agricultural net
◆ Bobbin：Inner Diameter 35/38/50/90mm Length 230/270mm
|
Model |
SJPL-Z120×33-1200×2 |
SJPL-Z130×33-1500×2 |
|
*Max. melting capacity |
500kg/h |
600kg/h |
|
Main motor power |
160kw |
200kw |
|
Screw diameter |
Ф120mm |
Ф130mm |
|
Die lip length |
1200mm×2 |
1500mm×2 |
|
**Max. production speed |
300m/min |
300m/min |
|
Number of winder |
280spindles |
360spindles |
|
Overall dimensions（L×W×H)） |
39500×4000×3500mm |
46000×5000×3500mm |
*Related to the use of melt pump
**Related to the fineness of raw materials and products
Optional device
|
Multi-station weighing and mixing system High-precision gear pump system Automatically controlled flat die Film thickness measurement system |
Additional heat setting roller Chill roll system Chiller Cooling tower |
Specification and dimensions are subject to change without prior notice.
